    WIRE ROPE CABLE GRIP
    Loading file
    • Fullscreen
    • Wireframe
    • Zoom In
    • Zoom Out
    • Rotation
    • Screenshot
    • Help

    Controls

    ×
    • Rotate with the left mouse button.
    • Zoom with the scroll button.
    • Adjust camera position with the right mouse button.
    • Double-click to enter the fullscreen mode.
    • On mobile devices swipe to rotate.
    • On mobile devices pinch two fingers together or apart to adjust zoom.
    • On mobile devices 3 finger horizontal swipe performs panning.
    PRODUCT NO.
    ET24WRCG-BT01
    Get The Latest Quotes
    Application:

    Wire Rope Cable Grip is a device for pulling, gripping and tensioning unsheathed wire ropes, cables, and metal rods in all forms. The parallel jaws provide a firm, non-slip grip without causing damage to the wire. A special spring-loaded guide prevents the grip from dropping off the wire and affords instand release without jamming.



    Features:

    Additional information

    Material:

    STEEL
    Finish:

    Electro-Galvanizing
    Capacity：

    5000lbs – 12000lbs
    Wire Size:

    Min. 0.18 in. – 0.70in.
    Max. 0.60 in. – 1.25in.
    Packing:

    Carton&Plywood Pallet/Crate
    BALL CLEVIS
    BALL CLEVIS
    Material:

    Forged steel.
    Clevis pins, bent clevis bolts and nuts are steel.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    ANSI Class: 52-3 & 5
    Ultimate Strength:

    30000lbs
    Packing:

    Carton&Plywood Pallet/Crate
    SOCKET EYES
    SOCKET EYES
    Material:

    Ductile iron, grade 654512.
    Clevis pins are C-1040 steel.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    18000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    SUSPENSION CLAMPS
    SUSPENSION CLAMPS
    Material:

    Clamp body and keeper are Aluminum alloy.
    Clevis pins, u-bolts, nuts and washers are steel.
    Cotter keys are stainless steel.
    Ultimate Strength:

    25000lbs
    Packing:

    Carton&Plywood Pallet/Crate
