    PRODUCT NO.
    WL23TREN-LT01
    Get The Latest Quotes
    Application:

    The thimble eye nut is assembled with the thread end of eye bolt, which goes across the wooden pole for supporting the strain insulators to the dead end wire, the triple-eye nut is used with three guys.

    Features:

    Additional information

    Bolt Diameter:

    1“
    Strength Ratings:

    36000 lbs
    Material:

    Steel
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
    POLE EYE PLATE
    POLE EYE PLATE
    Material:

    Ductile iron
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Strength Rating:

    20,000 lbs. at 45 and 90 degrees
    Packing:

    Carton&Plywood Pallet/Crate
    QUADRANT STRAIN CLAMPS
    QUADRANT STRAIN CLAMPS
    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    20000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    SUSPENSION CLAMPS
    SUSPENSION CLAMPS
    Material:

    Clamp body and keeper are Aluminum alloy.
    Clevis pins, u-bolts, nuts and washers are steel.
    Cotter keys are stainless steel.
    Ultimate Strength:

    25000lbs
    Packing:

    Carton&Plywood Pallet/Crate
