    PRODUCT NO.
    WL23TC-BT01
    Get The Latest Quotes
    Application:

    The Thimble Clevis is designed for use in conjunction with Dead-Ends for cable termination purposes.

    The thimble provides a smooth internal contour to prevent stress concentration within the loop of a Dead-End. The Clevis includes a steel pin which links the clevis through the eye of the insulator or other mounting point and the pin is secured with a humpbacked cotter key.

    Features:

    Additional information

    Material:

    Ductile iron
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
    QUADRANT STRAIN CLAMPS
    QUADRANT STRAIN CLAMPS
    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    20000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    BALL CLEVIS-30
    BALL CLEVIS-30
    Material:

    Body and Hardware: Steel
    Pin: Stainless Steel
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton & Plywood Pallet & Crate
    ANCHOR SHACKLE
    ANCHOR SHACKLE
    Material:

    Forged steel.
    Clevis pins and clevis bolts are high strength steel.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    25000 lbs
    Packing:

    Carton&Plywood Pallet/Crate
