    SUSPENSION CLAMPS
    Loading file
    • Fullscreen
    • Wireframe
    • Zoom In
    • Zoom Out
    • Rotation
    • Screenshot
    • Help

    Controls

    ×
    • Rotate with the left mouse button.
    • Zoom with the scroll button.
    • Adjust camera position with the right mouse button.
    • Double-click to enter the fullscreen mode.
    • On mobile devices swipe to rotate.
    • On mobile devices pinch two fingers together or apart to adjust zoom.
    • On mobile devices 3 finger horizontal swipe performs panning.
    PRODUCT NO.
    ETSC-001
    Get The Latest Quotes
    Application:

    For suspending galvanized steel overhead ground wire.

    Designed to allow a maximum conductor take-off angle of 30° Available with or without socket or clevis fittings.

    Features:

    Additional information

    Material:

    Clamp body and keeper are Aluminum alloy.
    Clevis pins, u-bolts, nuts and washers are steel.
    Cotter keys are stainless steel.
    Ultimate Strength:

    25000lbs
    Packing:

    Carton&Plywood Pallet/Crate
