    STRAIGHT-LINE DEAD END CLAMPS
    Loading file
    • Fullscreen
    • Wireframe
    • Zoom In
    • Zoom Out
    • Rotation
    • Screenshot
    • Help

    Controls

    ×
    • Rotate with the left mouse button.
    • Zoom with the scroll button.
    • Adjust camera position with the right mouse button.
    • Double-click to enter the fullscreen mode.
    • On mobile devices swipe to rotate.
    • On mobile devices pinch two fingers together or apart to adjust zoom.
    • On mobile devices 3 finger horizontal swipe performs panning.
    PRODUCT NO.
    ETSDEC-001
    Get The Latest Quotes
    Application:

    For distribution deadening. Recommended for use with galvanized steel static wire and distribution conductor.

    The keepers on all clamps feature lifting eyes to facilitate hot line work. Available with or without socket or clevis fittings.

    Features:

    Additional information

    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot-dip galvanized per ASTM A-153.
    Ultimate Strength:

    5000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    QUADRANT STRAIN CLAMPS
    QUADRANT STRAIN CLAMPS
    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    20000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    SOCKET EYES
    SOCKET EYES
    Material:

    Ductile iron, grade 654512.
    Clevis pins are C-1040 steel.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    18000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    THIMBLE EYE NUT-TRIPLE EYE
    THIMBLE EYE NUT-TRIPLE EYE
    Bolt Diameter:

    1“
    Strength Ratings:

    36000 lbs
    Material:

    Steel
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
