    PRODUCT NO.
    ETSE-001
    Get The Latest Quotes
    Application:

    For attaching ball and socket insulators to other associated tower hardware.

    Features:

    Additional information

    Material:

    Ductile iron, grade 654512.
    Clevis pins are C-1040 steel.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    18000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
    SUSPENSION CLAMPS
    SUSPENSION CLAMPS
    Material:

    Clamp body and keeper are Aluminum alloy.
    Clevis pins, u-bolts, nuts and washers are steel.
    Cotter keys are stainless steel.
    Ultimate Strength:

    25000lbs
    Packing:

    Carton&Plywood Pallet/Crate
    INSULATED DEADEND CLEVIS
    INSULATED DEADEND CLEVIS
    Material:

    Hot rolled channel steel.
    Finish:

    Hot dip galvanized per ASTM A-153.
    Accommodates Insulator:

    ANSI 53-2&53-3
    Packing:

    Carton&Plywood Pallet/Crate
    STRAIGHT-LINE DEAD END CLAMPS
    STRAIGHT-LINE DEAD END CLAMPS
    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot-dip galvanized per ASTM A-153.
    Ultimate Strength:

    5000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
