    PRODUCT NO.
    ET24SHE-BT01
    Get The Latest Quotes
    Application:

    HELIX EXTENSION is one of the components of square-shaft multi-helix screw anchor. Extension shafts must be coupled to the helix section for installation to the proper depth.

    Features:

    Additional information

    Material:

    STEEL
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
    ANCHOR EXTENSION -3’6″
    ANCHOR EXTENSION -3’6″
    Material:

    Steel
    Finish:

    Hot Dip Galvanized as per ASTM A153
    Ultimate Strength:

    70,000lbs
    Installation Torque:

    7,000 ft lbs
    TWO HELIX EXTENSION
    TWO HELIX EXTENSION
    Material:

    STEEL
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
    HELICAL PILES
    HELICAL PILES
    Material:

    STEEL
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
