    PRODUCT NO.
    ETDCL-30
    Get The Latest Quotes
    Application:

    Double clevis links are designed for linking all popular sizes of chain to rings, end links, eye hooks, pad eyes, etc.
    – Links for general applications
    – Intended for use with chain of equal or lower safe working load

    Features:

    Additional information

    Material

    STEEL
    Finish

    Hot Dip Galvanized per ASTM A-153
    Ultimate Strength

    30,000 lbs
    Packing

    Carton&Plywood Pallet/Crate
    HOOK GUY ATTAHMENTS
    HOOK GUY ATTAHMENTS
    Material:

    Ductile iron
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Strength Rating:

    15000lbs
    Packing:

    Carton&Plywood Pallet/Crate
    SUSPENSION TRUNNION CLAMPS
    SUSPENSION TRUNNION CLAMPS
    Material:

    Body & Keeper are Ductile iron
    Hardwares are Steel
    Finish:

    All parts are hot dip galvanized per ASTM A-153
    Diameter Range:

    0.25''-1.26''
    Packing:

    Carton&Plywood Pallet/Crate
    QUADRANT STRAIN CLAMPS
    QUADRANT STRAIN CLAMPS
    Material:

    Clamp body and keeper are ductile iron, grade 654512.
    Clevis pins, u-bolts, nuts and washers are steel.
    Socket and clevis fittings are ductile iron, grade 654512.
    Cotter pins are stainless steel.
    Finish:

    All parts, except cotter pins, hot dip galvanized per ASTM A-153.
    Ultimate Strength:

    20000 lbs
    Packing:

    Carton&Plywood Pallet&Crate
