    PRODUCT NO.
    WL24CVD-BT02
    Get The Latest Quotes
    Application:

    Cable Vibration Damper are solid dampers used to help suppress the vibrational impact on outdoor electrical structures caused by windy weather, limiting the damage caused to fragile cables and wires.

    Features:

    Additional information

    Clamp Material:

    Aluminium Alloy
    Hammer Head Material:

    Grey Cast Iron,Painted
    Weight(kg):

    2.2-12.9
    Span:

    100m,150m,200m,300m,400m
    Packing:

    Carton & Plywood Pallet/Crate
    THIMBLE EYE NUT-TWIN EYE
    THIMBLE EYE NUT-TWIN EYE
    Bolt Diameter:

    1”
    Strength Ratings:

    36000 lbs
    Material:

    Steel
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
    INSULATED DEADEND CLEVIS
    INSULATED DEADEND CLEVIS
    Material:

    Hot rolled channel steel.
    Finish:

    Hot dip galvanized per ASTM A-153.
    Accommodates Insulator:

    ANSI 53-2&53-3
    Packing:

    Carton&Plywood Pallet/Crate
    THIMBLE EYENUT
    THIMBLE EYENUT
    Bolt Diameter:

    5/8"/3/4"
    Maximum Strand:

    1/2"
    Strength Ratings:

    23000 lbs
    Material:

    Ductile iron, grade 654512.
    Finish:

    Hot Dip Galvanized per ASTM A-153
    Packing:

    Carton&Plywood Pallet/Crate
