Anchor Rods

ANCHOR EXTENSION -7′
Loading file
  • Fullscreen
  • Wireframe
  • Zoom In
  • Zoom Out
  • Rotation
  • Screenshot
  • Help

Controls

×
  • Rotate with the left mouse button.
  • Zoom with the scroll button.
  • Adjust camera position with the right mouse button.
  • Double-click to enter the fullscreen mode.
  • On mobile devices swipe to rotate.
  • On mobile devices pinch two fingers together or apart to adjust zoom.
  • On mobile devices 3 finger horizontal swipe performs panning.
PRODUCT NO.
ETAE-7
Application:

The anchor extension is used to extend the pile length so that the Lead section is placed at the proper depth. The Helical Shaft system is used in applications where tension, compression or both types of structure loading is required. It provides a predicatable foundation solution for significat load capacities

Features:

Additional information

Material:

Steel

Finish:

Hot Dip Galvanized as per ASTM A153

Ultimate Strength:

70,000lbs

Installation Torque:

7,000 ft lbs
